Technical features:

Polyurethane sealing on the end face, no need to plug the sealing ring, reducing labor intensity; Input the diameter of the steel pipe on the touch screen, and the device automatically locates the center of the steel pipe, reducing the difficulty of operation; The clamping and pulling device design can pull the steel pipe out of the sealing ring, solving the problem of the steel pipe not being able to detach from the sealing ring.

Device function:

This equipment is used for hydraulic testing of steel pipes to check for leakage under the specified pressure, in order to ensure the performance of the steel pipes.

Process Description:

The process of steel pipe pressure testing can be divided into: feeding - pressure testing - air water - discharge

Before the steel pipe is placed on the receiving platform, it must be aligned, and a pressure test head sealing ring must be selected according to the pipe diameter and wall thickness. The output pressure value should be adjusted according to the test pressure, and the lifting height of the device should be raised.
